The C6 is an ultra-compact, high-performance thermal imaging module engineered for strict SWaP (Size, Weight, and Power) applications. Delivering a crisp 640x512 thermal feed over standard CVBS analog video, and weighing just 25.5g, it is optimized for seamless integration into drone gimbals, handheld night vision devices, and localized surveillance systems.
Application Fields
-
Airborne Payloads : Minimal mass (25.5g) preserves flight endurance and gyro responsiveness.
-
FPV & Tactical Systems : Zero-latency analog CVBS transmission for real-time navigation and pilot awareness.
-
Security & Local Monitoring: Small footprints allow discrete placement inside rugged enclosures.
Key Features :
-
Advanced 35mK Sensitivity : Features a 12μm uncooled VOx sensor with NETD ≤25mK for sharp thermal contrast and fine target detailing.
-
Ultra-Lightweight & Compact : Weighs only 25.5g with an ultra-small 21x21x34.2mm form factor, reducing strain on mobile payloads.
-
Seamless Analog Integration : Standard CVBS (PAL format) output paired with a universal 5-pin 1.25mm connector makes deployment effortless.
-
Long-Range Detection : Paired with a 9mm lens, it achieves a vehicle/human detection range of up to 900 meters.
- Wide Power Input : Supports a flexible 5V to 18V DC power range, adapting easily to various battery setups and industrial power lines.
